2m2 STS304 Straight Hole Pulp Screen Plate High Vibration Screen Pulp Making Machine Licht Verwijdering van onzuiverheden
2m2 STS304 Rechte Gaten Zeefplaat Hoge Vibratie Zeef Pulp Machine Lichte Onzuiverheden Verwijdering
1. Goede slijtvastheid en lange levensduur, meer dan tien keer die van metalen zeven, 3-5 keer die van gewone rubberplaten, en 2-3 keer die van roestvrij staal.
2. De kosten per ton mineraalverbruik zijn lager dan die van metalen zeefgaas.
3. Goede weerstand tegen vocht en slijtage.
4. Schokabsorptie en geluidsreductie, meer dan 10 dB lager dan metalen zeefplaat (gaas).
5. Automatische reiniging is goed, vanwege de kenmerken van de secundaire trilling van polyurethaan, blokkeert het de gaten niet, hoge zeefefficiëntie
6. Gietwerk slijtvaste boss zeef, slijtvast en goedkoop
Prestatiekenmerken:
1. De meerlaagse zandcontrolefilterhuls heeft een hoog-efficiënte zandcontroleprestatie, die de zanddeeltjes in de formatie beter kan blokkeren en voldoet aan de zandcontrolebehoeften ondergronds.
2. Uniforme filterporiën, hoge doorlaatbaarheid en anti-blokkerende prestaties.
3. Groot filteroppervlak, kleine stroomweerstand en hoge olie-output rate
4. Uitstekende corrosiebestendigheid van roestvrij staal, weerstand tegen zuur-, alkali- en zoutcorrosie, kan voldoen aan de speciale eisen van olieputten, en de spleet zal niet geleidelijk toenemen door corrosie.
5. De meerlaagse structuur is aan elkaar gelast, wat de filterporiën kan stabiliseren en een sterke weerstand tegen vervorming heeft.
| Model | PVS-1 | PVS--2 | PVS-3 | PVS-4 |
| Capaciteit (T/D) | 8-16 | 20-40 | 40-80 | 60-120 |
| Zeefoppervlak (m2) | 0.6 | 1 | 2 | 3 |
| Zeefplaatafmeting mm | 500×1300 | 580×2100 | 1080×2100 | 1580×2100 |
| Watersproei (L/min) | 15~30 | 20~40 | 30~60 | 50~100 |
| Trillingsfrequentie (keer/min) | 710 | 710 | 710 | 710 |
| Amplitude (volledige amplitude) mm | 10~12 | 10~13 | 10~15 | 10~15 |
| pulp inlaat mm | 70×240 | 150×300 | 150×300 | 150×300 |
| Motor model | Y132S-8 | Y132M-8 | Y160M-8 | Y160S-8 |
| Vermogen (KW) | 2.2 | 3 | 4 | 5.5 |
| Rotorsnelheid (r/min) | 710 | 710 | 710 | 710 |
| Gewicht (zonder motor)kg | 807 | 1000 | 1200 | 1500 |
| Totale afmeting (L X B X H)mm | 2169×2030×1160 | 2780×2100×1300 | 2780×2560×1400 | 2780×3100×1400 |




STS304 rechthoekschermplaat van pulp
,2m2 hoogtrillingspulp-schermplaat
,Lichte onzuiverheidsverwijderingspulpcreen
-
